SVH-M24
Key Features
- Static Eliminator Using Vacuum Ultra Violet Ray
- Electrostatic electricity can be removed from inert gases such as N2 and Ar
- Maximum power performance under pressure-sensitive vacuum
- Minimizing process impact with low heat generation compared to other companies
- Minimize exposure to UV light sources through real-time On/Off control (less than 1 second)
- Information on Head Fail and Replacement is displayed in real time
Download
You will receive catalogues, manuals and leaflets.
Technical Support & Customer Support
Specifications
| Parameter | Description / Value | |
|---|---|---|
| Radiant Wavelength Range | 100nm to 200nm | |
| Window Material | MgF2 | |
| Cooling Method | Air cooling by cooling fan | |
| Operation | Temperature | 1℃ to 40℃ |
| Humidity | 20% to 90% RH | |
| Storage | Temperature | -40℃ to 70℃ |
| Humidity | 90% RH | |
| Weight | 0.56kg | |
| Guaranteed Service Life | 1 Year(보증기간) or 2,000Hr(보증사용 시간) | |
Decay Time Characteristics
- Electrostatic performance over distance
- Vacuum Level : 10⁻⁷ torr
- Charged Voltage : ±1000V → ±100V (150mm x 150mm Plate)
- Window to Charge Plate : 200mm ~ 2000mm
- Vacuum Chamber : Ø400 x 2300L STS Cylinder
- The performance of the power supply may vary depending on the installation environment and conditions.
- Antistatic performance according to pressure changes
- Vacuum Level : 10⁻¹ ~ 10⁻⁷ torr
- Charged Voltage : ±300V → ±30V (150mm x 150mm Plate)
- Window to Charge Plate : 2000mm
- Vacuum Chamber : Ø400 x 2300L STS Cylinder
- The performance of the power supply may vary depending on the installation environment and conditions.
Dimensions
